BASURI ® MUSICAL HORN 3.0 - 20 MELODY AIRHORN - 24V

BASURI® MUSICAL AIRHORN - 3.0 - 24V

- 20 different melodies (full list below)
- 24V
- 6 air horns
- Super quality
- + 130dB - extremely loud !!

Includes:
- 6 pre-assembled horns
- Controller = Control / selection panel
- 6mm connection for air hose

Edit:
Preferably to have the air horn installed by a trained technician
- Red = + power
- Black = - mass
- Gray = ground (switched)
- Preferably provide the power supply with a fuse or relay.
- There must be an air supply on the vehicle - not included
- Provide a 5A fused power source
- Working pressure 8 to 10 bar

- 1 year warranty

Melodies:
00 TONE HIGH - LOW
01 BABY SHARK 3.0
02 BELIEVER
03 LA CUCARACHA
04 MAGIC IN THE AIR
05 OLD MACDONALD HAD A FARM
06 SQUID GAME
07  WILLIAM TELL OVERTURE
08 THE IMPERIAL MARCH
09 WE LIKE TO PARTY - VENGABUS
10 MACARENA
11 PINK PANTHER
12 KILL BILL WHISTLE
13 WE NO SPEAK AMERICANO
14  JAMES BOND ENTERY
15 HOTEL ROOM SERVICE - PITBULL
16 INDUSTRY BABY
17 SMOKE WEED EVERYDAY
18 FUR ELISE - BEETHOVEN
19 KIMI NO TORIKO

Installing the Basuri.

Controller.
a. The controller must be continuously powered by 24V on the between the black and red cable.
A common mistake is that the power to the controller itself is also behind the switch.
b. The gray cable ensures that the selected melody is played, for this the gray cable must be connected to the – pole of the battery with the switch in between that you want to use to make the horn go off.

Wiring harness
a. Leave it intact, shortening will not improve the quality.
b. Only connect the horn set with a wire harness that is intact and the cables run from the controller.
We regularly see that the black cable that runs to the 6 coils on the horn set is cut and connected directly to the chassis, this does not work as the control signal from the valves also runs through the black cable.

Air connection
a. The air horn operates at an air pressure of 8 to 12 Bar.
b. Use a 6mm rigid PVC air hose to connect to the quick coupling, if you don't have one, art. KST13UN help you further.

Warning: Not allowed on public roads - Only for use on private property
This product is intended for private use only and may not be used on public roads. Using this product on public roads may result in fines and other legal consequences. We accept no liability for any fines or other problems arising from improper use of this product. Read the instructions for use carefully and only use the product as intended on private property.
